Balanced Input Impedance: 10k Ohms
Single-ended Line Input Impedance: 50k Ohms
Maximum Input Level Balanced: 5Vrms
Maximum Input Level Single Ended: 2.5Vrms
Maximum Output Level, RCA and XLR 5Vrms
Distortion at 1Vrms Output: <0.002% 1KHz
Dynamic Range: 125dB A-Weighted re: 5Vrms
Single-ended Line Out Impedance: 50 Ohms
Balanced Output Impedance: 100 Ohms
Output Connections: XLR and RCA Outputs
Power Usage On: 4W
Power Usage Off: 0.0W
Power Input: 100-120VAC, 220-240VAC 50/60 Hz
Littlefuse 214 Series, 3 ampere, time-lag, 250VAC, 5x20mm ceramic body fuse
8.5" W x 12" D x 3.5" H (216 mm x 305 mm x 88 mm)
Weight: 13lbs. (6.5 kg)
Features and specifications are subject to improvements and changes without prior notice.
