TECHNICAL SPECIFICATIONS
Plinth & Chassis
Design: Sandwich structure of plywood, aluminum, and stainless steel
Feet: 3 stainless steel feet with porcelain inserts or optional spikes
Dimensions: 300 × 500 × 200 mm (without tonearm)
Weight: 29 kg
Platter
Material: Delrin
Diameter: 300 mm
Weight: 6.5 kg
Main Bearing
Type: Inverted hydrodynamic journal bearing
Materials: Aluminum, PEEK, hardened steel, YG8 (carbide ball)
Spindle: 15 mm stainless steel
Lubrication: Synthetic oil
Maintenance: Every 3 years (optional cleaning)
Drive System
Motor: BLDC, 3-phase, 8-pole, 20 W
Speeds: 33.3 and 45 RPM
Speed control: Open-loop, 1 sensor per revolution (HALL sensors)
Functions: Soft start/stop, last-speed memory
Belt: Ø 3 mm
Wow & Flutter: < 0.07% (measured)
Tonearm
Length: 12.5 inches
Effective mass: 13–21 g (depending on headshell)
Headshells: Carbon fiber (4.7 g), Titanium (14.9 g)
Adjustments: VTA on-the-fly, anti-skating, standard oil damping
Wiring: silver, with Furutech RCA connectors
Power Supply
Type: ULPS DC
Input: 110/220V AC
Output: 12V DC, 5.5–2.5 mm connector
