Supported sampling frequency: ZERO LINK, USB: Max. 768kHz (PCM) / Max. 22.6MHz (DSD)
Coaxial, AES/EBU:Max. 192kHz (PCM) / Max. 2.8MHz (DSD64 DoP v1.1)
PCM quantization bit rate: ZERO LINK, USB: 16bit, 24bit, 32bit
Coaxial, AES/EBU: 16bit, 24bit
Digital input: ZERO LINK, USB (Typ B) 2, coaxial (S/PDIF), AES/EBU
External clock input: 10MHz (SMA 50ohms)
Analog output: XLR x1, RCA x1
Analog output level: XLR: 5,6Vrms, RCA: 2,8Vrms
Frequency characteristic: 2Hz bis 120kHz (+0/-1dB）
S/N ratio: 110dB
Total harmonic distortion: 0,008％ (NOS/176,4kHz)
Analog filter: Primary passive type
Power voltage: 230V AC 50Hz
Power consumption: 48v
Maximum external dimensions: Main unit: 454(W) × 174(H) × 407(D)mm
Weight: 28kg
Included accessories:Spike board, spikes, remote controller, power cable
